National Item Identification Number
00-284-5095
002845095
5975-00-284-5095
5975002845095
National Stock Number
Item Name
BOX CONNECTOR,ELECTRICAL
Federal Supply Class
5975
Referenced on: http://trucks10ton.tpub.com//TM-5-5420-234-14-P/TM-5-5420-234-14-P1519.htm
Referenced on: http://trucks10ton.tpub.com//TM-5-5420-234-14-P/TM-5-5420-234-14-P1527.htmDescription
An item designed to mechanically connect in a straight line or an angle electrical conduit, conduit assemblies, wire, wireway, cable, or cable assemblies to a point of termination, such as a junction box, conduit outlet, or the like. The termination end must have an external thread with a boss or shoulder and may be furnished with a locknut or bondnut; or, must have internal thread with which is furnished an externally threaded hub with a wrenching feature; or be of a snap-in type that may be installed from either inside or outside the box and secured with a captive screw. It is not intended to join conduit to conduit. For angle type items having a male thread without a boss or shoulder, see ELBOW, ELECTRICAL CONDUIT. Does not include facilities to mount wiring devices. Excludes CHASE NIPPLE, CONDUIT.
Commercial and Government Entity Code (Supplier Data)
79500
91340
1VPW8
GENERAL DYNAMICS C4 SYSTEMS INC.
DBA PREVIOUSLY - GENERAL DYNAMICS
8201 E MCDOWELL RD
SCOTTSDALE
AZ
85257
800-424-0052
D1901
03743
EGS ELECTRICAL GROUP
APPLETON DIV
7770 FRONTAGE RD
SKOKIE
IL
60077
847-679-7800
19204
NSN (National Stock Number) 5975-00-284-5095, 5975002845095 NIIN (National Identification Number) 00-284-5095, 002845095
Part Numbers (Reference Numbers)
CG-3750
M7472148REV8PT8
13213E4415-11
58K802932
58K802932
5900009-0000-000;
Required Categories
STYLE DESIGNATOR
CABLE DIAMETER ACCOMMODATED
MATERIAL
THREAD SERIES DESIGNATO
Required Description
A23 STRAIGHT
0.500 INCHES NOMINAL FIRST END
ALUMINUM ALLOY
NPT SECOND END
0.
